AC Power Supply 10gb Layer 3 Switch With 28 Ports, VLAN Support For Network

Place of Origin Shenzhen,China
Brand Name Sirivision
Certification CE, ROHS, FCC, UKCA
Model Number SR-ST316F8C4T
Minimum Order Quantity 20
Price Negotiation
Packaging Details 1pc in box, 1pc Warranty Card in box
Delivery Time 5-8 work days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 50000pcs Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power Supply AC100~240V 50/60Hz Layer 3
VLAN Support Yes Warranty 1 Years
Routing Protocols Static Routing Product Name 10gb Layer 3 Switch
QoS Yes
High Light

VLAN Support 10gb Layer 3 Switch

,

10gb Layer 3 Switch For Network

Leave a Message
Product Description

Product Description:

10gb Layer 3 Switch - High-Performance Network Switch for Enterprise-Level Businesses

The 10gb Layer 3 Switch is a powerful and reliable network switch designed for enterprise-level businesses. With its advanced features and robust design, this switch offers seamless and secure network management for your organization.



VLAN Support: Yes

The 10gb Layer 3 Switch supports VLAN (Virtual Local Area Network) technology, allowing you to create multiple virtual networks within a single physical network. This enables you to easily segment your network for better security, efficiency, and performance.



High-Performance 10gb Network Switch

Equipped with 28 high-speed ports and 4 SFP+ ports speed of 10Gbps, this switch provides lightning-fast data transfer rates for your network. It is ideal for bandwidth-intensive tasks such as video streaming, large file transfers, and data backups.



Robust and Reliable Design

The 10gb Layer 3 Switch is built to withstand the demands of enterprise-level networks. Its sturdy and durable rack-mountable form factor ensures it can be easily integrated into your existing network infrastructure without taking up too much space.



Scalability and Flexibility

As your business grows, so does your network. The 10gb Layer 3 Switch offers scalability, allowing you to add more ports and expand your network as needed. It also supports different types of network connections, including copper and fiber, providing flexibility for your network setup.



Seamless Network Management

The 10gb Layer 3 Switch offers seamless network management through its intuitive web interface and command-line interface. This allows you to easily configure and monitor your network, ensuring optimal performance and security at all times.



Secure Network Connections

The 10gb Layer 3 Switch comes with built-in security features, including access control lists and network segmentation, to protect your network from unauthorized access and potential threats. This ensures the safety and confidentiality of your data.



1-Year Warranty

We stand behind the quality and reliability of our product, which is why the 10gb Layer 3 Switch comes with a 1-year warranty. This gives you peace of mind and confidence in your network infrastructure.

Upgrade your network to the 10gb Layer 3 Switch and experience high performance, advanced features, and secure network management for your enterprise-level business. Contact us today to learn more.



Features:

  • Product Name: 10gb Layer 3 Switch
  • QoS: Yes
  • Form Factor: Rack-mountable
  • Security:
    • 802.1X
    • SSH
    • SSL
    • ACLs
  • Warranty: 1 Year
  • 10gbps switch
  • 10gb switch
  • Layer 3 switch
  • Advanced security
  • High performance
  • Reliable
  • Flexible
  • Easy management


Technical Parameters:

Product Name 10gb Layer 3 Switch
Ports 4x 10Gbps SFP+, 16x 1Gbps SFP, 8x 1Gbps Combo ports,1x Console port
Warranty 1 Years
Power Supply AC100~240V 50/60Hz
Form Factor Rack-mountable
Indicators SFP fiber port indicators, power input indicator, system running indicator
Management Web-based GUI, CLI, SNMP
Port Number 28
Layer 3
Routing Protocols OSPF, BGP, RIP, VRRP(Developing)
VLAN Support Yes
Standards IEEE 802.3i,802.3u,802.3ab,802.3x,802.3z
Network Media (Cable) 10Base-T: UTP category 3, 4, 5 cable (Max100m) 100Base-Tx: UTP category 5, 5e cable (Max100m) 1000Base-T: UTP category 5e, 6 cable (Max100m) 1000BASE-SX: 62.5um MMF (min. range: 2m~275m) or 50um MMF (min. range: 2m~550m) 1000BASE-LX: 62.5um/50um MMF (min. range: 2m~550m) or 9um SMF (min. range: 2m~5000m) 10GBASE-SR: OM1/OM2/OM3 or above MMF (operating range: 2 m ~ 300 m) 10GBASE-LR: IEC's B1.1 and B1.3 SMF (min. range: 2 m ~ 10,000 m)
Dimensions 430mm*290mm*46mm
Transfer Method Store-and-Forward
MAC Address Table 16K
Switching Capacity 128Gbps
Packet Forwarding Rate 95.232Mpps
Packet Buffer 12Mbit
Jumbo Frame 12KBytes
Environment Operating Temperature: 0℃ ~45℃ (0℉~113℉) Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing



Soft Features:

L3 Features IPV4/IPV6
Dynamic ARP
L2 Features Flow Control
802.3x (full duplex)
Back pressure (half duplex)
Link aggregation
Spanning Tree 802.1D (STP),802.1w (RSTP),802.1s (MSTP)
ERPS,BPDU Filtering
Automatic Edge Port
VLAN 8 groups Protocol-based VLAN
support VLAN Translation
256 MAC-based VLAN
Voice VLAN
Monitoring VLANs
IEEE802.1q VLAN,QinQ (IEEE 802.1ad),GVRP,Private VLAN,GVRP,VLAN VPN
4096 static VLANs
multicast IGMP Snooping(v1,v2,v3)
MVR, MLD Snooping V1/V2
Multicast VLAN Registration (MVR)
QoS 8 priority queues per port
Support port-based and VLAN-based PolicyMap binding
TOS, DSCP, 802.1p priority field rewrites
Queue Scheduling WRR,WFQ,WRR+SP, WFQ+SP
Support flow classification based on ACL flow, COS, TOS, DSCP
ACL Custom ACL, MAC-based, IP-based, port-based
Security Features IEEE 802.1X certification,Guest VLAN,Port-based,Host-based,MAC Auth,Web Auth
Storm Control, Ports Security,Port Isolation
DHCP Snooping,CPU Defence Engine,DoS Prevention,256 IP Source Guard
Dynamic ARP Check,IP,MAC,Port Binding,Dynamic VLAN Assignment,Management Access,
HTTPS,BPDU,SSH v1/v2,8 TACACS+,8 RADIUS
Management Supported CLI, Console, SNMP v1/v2/V3, Web, RMON management
Diagnosis mirror Many-to-One
UDLD,System Log (RFC3164)
System Diagnosis,Port Diagnostics,Network Diagnosis



Applications:

Sirivision 10gb Layer 3 Switch

Brand Name: Sirivision

Place of Origin: Shenzhen, China

Port Number: 4x 10Gbps SFP+ slots, 16x 1Gbps SFP and 8x 1Gbps Combo ports.

VLAN Support: Yes

Management: Web-based GUI, CLI, SNMP

Routing Protocols: OSPF, BGP, RIP, VRRP(Developing)



Sirivision 10gb Layer 3 Switch is an advanced high-speed network switch designed for efficient and reliable performance in enterprise-level network infrastructures. With a capacity of 10 gigabits per second, this switch is ideal for large-scale IT environments such as data centers and corporate campuses.



Product Features:

  • High Speed: With 10 gigabit ports, Sirivision 10gb Layer 3 Switch offers blazing-fast data transfer speeds and advanced features for maximum efficiency.
  • Flexibility: The switch supports multiple VLANs, allowing for network segmentation and traffic prioritization to optimize network performance.
  • Remote Management: The switch can be managed remotely through a web-based GUI, CLI, or SNMP, providing centralized control over the network.
  • Network Security: With support for VLANs and routing protocols such as OSPF, BGP, RIP, and VRRP(Developing), the switch ensures network security and fault tolerance to protect against potential threats.
  • Reliability: With features such as load balancing, the switch ensures reliable network performance even in high-demand environments.

Application Scenarios:

  • Data Centers: Sirivision 10gb Layer 3 Switch is ideal for large-scale data centers that require high-speed and reliable network infrastructure for efficient data transfer and management.
  • Corporate Campuses: In large corporate campuses, the switch can be used for network segmentation and centralized control to ensure smooth communication between different departments.
  • Large-Scale IT Environments: The switch is also suitable for large-scale IT environments such as universities, hospitals, and government agencies that require a high-performance and scalable network infrastructure.
AC Power Supply 10gb Layer 3 Switch With 28 Ports, VLAN Support For Network 0

Customization:

10gb Layer 3 Switch - Sirivision Customization

Brand Name: Sirivision

Place of Origin: Shenzhen, China

Warranty: 1Years

Power Supply: AC

Form Factor: Rack-mountable

Layer: 3

VLAN Support: Yes

Looking for a high-performance 10gb network switch? Look no further than Sirivision's 10gb Layer 3 Switch. Based in Shenzhen, China, Sirivision offers top-of-the-line customization services to meet your specific networking needs.

With a 1-year warranty and reliable AC power supply, our 10gb Layer 3 Switch is built to last. Its rack-mountable form factor allows for easy installation and integration into your network setup.

As a Layer 3 switch, it offers advanced routing capabilities for efficient and secure data transmission. Our switch also supports VLAN, providing a flexible and scalable solution for network segmentation.

Don't settle for less when it comes to your networking infrastructure. Choose Sirivision's 10gb Layer 3 Switch for unparalleled performance and reliability. Contact us today to discuss your customization options!



FAQ:

  • Q: What is the brand name of this product?
  • A: The brand name of this product is Sirivision.
  • Q: Where is this product manufactured?
  • A: This product is manufactured in Shenzhen, China.
  • Q: What is the product type?
  • A: This product is a 10gb Layer 3 Switch.
  • Q: What are the key features of this product?
  • A: The key features of this product include 10gb bandwidth, Layer 3 switching, and advanced management options.
  • Q: How many ports does this switch have?
  • A: This switch has 28 ports.
  • Q: Can this switch be used for both data and voice networks?
  • A: Yes, this switch is designed to support both data and voice networks, making it a versatile choice for businesses.
  • Q: Is this switch compatible with other network equipment?
  • A: Yes, this switch is designed to be compatible with other network equipment, allowing for easy integration into existing systems.
  • Q: What is the warranty on this product?
  • A: Please refer to the warranty information provided by the manufacturer for details on the warranty for this product.
